Termorestringe colla 3:1 barra TA32 4.5/1.5
UNS 318-30450
| TA32-4.5/1.5-PO-X-BK
|
Dettagli
- Guaina termorestringente a parete sottile con adesivo interno
- Elevate caratteristiche ritardanti di fiamma
- La parete esterna rispetta la norma UL224
- Elevato rapporto di restringimento
Richiedi ora la tua offerta individuale
Richiedi un preventivo
Altri prodotti dello stesso gruppo:
| Applicazione | TA32/TA42 sono sviluppate per sigillare e per l'isolamento elettrico di giunzioni, terminazioni e componenti. |
| Application Tool | H6100 |
| Behaviour at Heat Shock | not cracking, not dripping, not fluid |
| Colour | Black (BK) |
| Heat Shock Test | 4h/250°C |
| Material | Polyolefin, cross-linked (PO-X) |
| PART DESCRIPTION | TA32-4.5/1.5-PO-X-BK |
| Pack Content | 250pcs. |
| Package Content packed in | pcs. |
| Printable | No |
| Product Family | TA32 - thin wall, 3:1 shrink ratio |
| Product Group | Heat shrinkable tubing adhesive lined - 1.2 m lengths |
| Shrink Ratio | 3:1 |
| Type | TA32-4.5/1.5 |
| Variant | Thin-Wall |
| With inner glue (Yes/No) | Yes |
Download
| Adhesive | Hot melt adhesive |
| CSA Certified | Yes |
| Dielectric Strength | 25kV/mm |
| Dielectric Strength test method | ASTM D876 |
| ELV compliant (Article 4 - 2) | YES |
| Elongation at break | 350% |
| Elongation at break test method | ASTM D638 |
| Flammability | UL 224 VW-1 |
| Halogen-free | No |
| Hazardous Goods | No |
| Min. Shrink Temperature - °C | +110 °C |
| Operating Temperature | -55 °C to +125 °C |
| ROHS compliant | Yes |
| Softening Point Adhesive | +110 °C |
| Specifications | ANSI/UL 224, C22.2 no. 198.1-99 |
| Specifications |
|
| Tensile Strength | 15MPa |
| Tensile Strength test method | ASTM D876 |
| Test Method Tensile Strength | ASTM D638 |
| UL OCD link | Link |
| UL Recognized (US and Canada) | Yes |
| Volume Resistance | 10¹⁴ Ω cm |
| Water Absorption | 0.5% |
