Clip a nastrare per bordi, L=50.0mm, SO=17.25mm, nero, 5000Pz.
UNS 151-01206
| EC48-PA66HIRHS-BK
|
Dettagli
Richiedi ora la tua offerta individuale
Richiedi un preventivo
Altri prodotti dello stesso gruppo:
| Colour | Black (BK) |
| Fixation Method | Edge Clip |
| Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| PART DESCRIPTION | EC48-PA66HIRHS-BK |
| Pack Content | 5000pcs. |
| Package Content packed in | carton |
| Product Family | Bundling Clips for Edges, 3.0 - 6.0 mm, for Distance Routing |
| Product Group | Bundling Clips for Edges for Distance Routing |
| Type | EC48 |
| Bundling Bar Length | 50.0mm |
| Height (H) | 14.83mm |
| Length (L) | 50.0mm |
| Length (L2) | 17.25mm |
| Offset Length | 17.25mm |
| Panel Thickness | 0.12 - 0.24" |
| Panel Thickness max. | 3.0 - 6.0mm |
| Panel Thickness max. (imperial) | 0.24" |
| Panel Thickness min. (imperial) | 0.12" |
| Width (W) | 29.71mm |
| for Panel Thickness min - max | 3 - 6 mm |
Download
| CE Certification | No |
| CSA Certified | No |
| ELV compliant (Article 4 - 2) | YES |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +110 °C |
| ROHS compliant | Yes |
| Specifications |
|
| UL Listed (US and Canada) | No |
| UL Listed (US and Canada) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US and Canada) | No |
| UV-Stabilised | No |
|
|
|
| GTIN-13 / EAN | 4031026711331 |
| Packaging 1 - Height (m) | 0.36m |
| Packaging 1 - Length (m) | 0.575m |
| Packaging 1 - Qty | 5000 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.059m³ |
| Packaging 1 - Weight (kg) | 15.065001kg |
| Packaging 1 - Width (m) | 0.285m |
| Packaging 3 - Height (m) | 0.3730625m |
| Packaging 3 - Length (m) | 0.587375m |
| Packaging 3 - Qty | 5000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.063m³ |
| Packaging 3 - Weight (kg) | 15.97kg |
| Packaging 3 - Width (m) | 0.2873375m |
| Packaging 4 - Height (m) | 1.269m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 60000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.218m³ |
| Packaging 4 - Weight (kg) | 211.38kg |
| Packaging 4 - Width (m) | 0.8m |
