Preformato a 2 vie 204-1-G
UNS 402-04180
| 204-1-G-PO-X-BK
|
Dettagli
- Riduzioni degli stress meccanici all'interno delle biforcazioni
Richiedi ora la tua offerta individuale
Richiedi un preventivo
Altri prodotti dello stesso gruppo:
Applicazione | Preformati termorestringenti per applicazioni in cablaggi elettrici ed elettronici. |
Application Tool | H6100, E4500, CHG900 |
Colour | Black (BK) |
Material | Polyolefin, cross-linked (PO-X) |
PART DESCRIPTION | 204-1-G-PO-X-BK |
Pack Content | 1pc. |
Package Content packed in | pcs. |
Product Family | Helashrink 200 Series |
Product Group | 2-Way Outlet Shapes, VG style |
Type | 204-1-G |
Variant | For 2-core cables |
Designation as per VG-Norm | VG 95343 T08 C 003 A |
Dielectric Strength | 15kV/mm |
Dielectric Strength test method | ASTM D2671 |
ELV compliant (Article 4 - 2) | YES |
Flammability | ASTM D635 |
Hazardous Goods | No |
Min. Shrink Temperature - °C | +135 °C |
Nato number | 5970-12-310-2122 |
Operating Temperature | -75 °C to +150 °C |
ROHS compliant | Yes |
Specifications | |
Specifications | VG 95343-8:2016-03 |
