Basetta per fissaggio a vite, Ø8.0 mm, Vite 5/16" (M8), grigio, 500Pz.
UNS 151-29600
| SAM83-PA66HIRHS-GY
|
Dettagli
- Guida i fasci al di sopra degli spigoli vivi
- Per perni filettati o viti
- Può essere utilizzato in combinazione con fascette heavy duty
- Per fascette con larghezza fino a 12,7 mm
Richiedi ora la tua offerta individuale
Richiedi un preventivo
Altri prodotti dello stesso gruppo:
Applicazione | Con queste caratteristiche per il fissaggio in ambienti difficili, offre eccellenti prestazioni nell'industria dei mezzi pesanti, navali costruzioni di veicoli. |
Colour | Grey (GY) |
Fixation Method | Screw Mounting and Rivet |
For Ties | T50 - T250 |
Key product features | vibration absorbing |
Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
Mounting Screw Type | 5/16" (M8) Screw |
PART DESCRIPTION | SAM83-PA66HIRHS-GY |
Pack Content | 500pcs. |
Package Content packed in | bag |
Product Family | SAM83 with a socket counter bore |
Product Group | Harness clip for heavy duty applications, for screws or threaded bolts for edges |
Type | SAM83 |
CE Certification | No |
CSA Certified | No |
ELV compliant (Article 4 - 2) | YES |
Flammability | UL 94 HB |
Hazardous Goods | No |
Operating Temperature | -40 °C to +110 °C |
ROHS compliant | Yes |
Specifications | |
UL Listed (US and Canada) | No |
UL Listed (US and Canada) | No |
UL Recognized (US and Canada) | No |
UL Recognized (US and Canada) | No |
UV-Stabilised | No |
|
|
GTIN-13 / EAN | 4031026312491 |
Packaging 1 - Height (m) | 0.07m |
Packaging 1 - Length (m) | 0.625m |
Packaging 1 - Qty | 500 |
Packaging 1 - Type | bag |
Packaging 1 - Volume (m³) | 0.01575m³ |
Packaging 1 - Weight (kg) | 3.874kg |
Packaging 1 - Width (m) | 0.36m |
Packaging 3 - Height (m) | 0.1508125m |
Packaging 3 - Length (m) | 0.4365625m |
Packaging 3 - Type | box |
Packaging 3 - Volume (m³) | 0.0176m³ |
Packaging 3 - Width (m) | 0.2667m |
